Nameplate on the pump casing using English units

Table 2: Explanation of nameplate on the pump casing

Nameplate field Explanation
IMPLR. DIA.

Impeller diameter, in inches

MAX. DIA.

Maximum impeller diameter, in inches

GPM

Rated pump flow, in gallons per minute

FT HD

Rated pump head, in feet

RPM

Rated pump speed, revolutions per minute

MOD.

Pump model

SIZE

Size of the pump

STD. NO.

Does not apply

MAT L. CONST. Material of which the pump is constructed
SER. NO.

Serial number of the pump

MAX DSGN PSI

@ 100F

Maximum pressure at 100ºF according to the pump design

Nameplate on the pump casing using metric units

Table 3: Explanation of the nameplate on the pump casing

Nameplate field

Explanation

IMPLR. DIA.

Impeller diameter

MAX. DIA.

Maximum impeller diameter

/HR

Rated pump flow, in cubic meters per hour

M HD

Rated pump head, in meters

RPM

Rated pump speed, in revolutions per minute
