EGG STATION (ES-600 & ES-1200)
15
P/N 1010871 Rev. D 08/05
1
0021327
Nose Piece Weldment
1
2
210K230
Bumper, Recess Leg 1”
1
(Set of 4 including 4 screws)
3
7000379
Grill Platen
1
4
040P138* Lock-nut, Conduit - 1/2” NPT
1
5
0400315
Strain Relief - Cord Connector
1
7 0010192 Service
Pan
2
11 0502900 Bracket
,
Sensor
1
12 7000363
Cover, Rack, & Ring Assembly 1
12a 7000261
Cover, Rack, & Ring Assembly 1
13 7000451
Cover, 12 Egg
1
(Includes 28, 48, 65)
13a 7000453
Cover, 6 Egg
1
(Includes 28, 48, & 65)
14 7000452
Rack, 12 Egg Ring
1
(Includes 27 & 45)
14a 7000454
Rack, 6 Egg Ring (Incl. 27 & 45) 1
15 0021324 Panel,
Base
1
16 0021325 Housing,
Main
1
18 0504075 Cover,
Insulation
2
19 0021326
Rear Panel Weldment
1
21 0504078 Bracket,
Hi-Limit
1
24 0700437
Power Cord, Harmonized
1
16
Amp,
IEC
309
0700453
Power
Cord,
Harmonized
1
16
Amp,
CEE
7/7
0700694
Power
Cord
Assembly
1
(AS3112
Australian
plug)
25 1001100 Label,
Control
1
26 210K122
Adj. Leg Kit (4 pack)
1
27 2100137 Knob
Ball
1
28 2100138 Knob-Ball
1
29 210K108
Rubber Tip Kit (4 pack)
1
31 2130111
Egg Ring (single)
12/6
213K101
Egg Ring (Pkg. of 6)
1/2
33 300P102* Nut,
Speed
#8-32
“U”
1
37 306P113* Screw, Mach.
2
#6-32 x 5/8” Sltrshd
38 306P123* Screw,
Mach.
4
#6-32 x 7/8” Sltrshd
2
39 306P130* Nut,
Hex
KEPS
#6-32
6
40 308P102* Washer,
Int.
Tooth
#8
1
41 308P104* Scr,
Mach
1
#8-32 x 3/8” Sltrshd
42 308P143* Nut,
Hex
KEPS
#8-32
1
43 308P157* Screw, Tap #8-32 x 3/8”
1
44 310P102* Washer,
Int
Tooth-lock
#10
2
45 310P109* Scr,
Mach
1
#10-32 x 3/8” Sltrshd
46 310P136* Scr,
Mach.
1
#10-32 x 1 and 1/4” Slpanhd
47 310P149* Scr,
Mach.
1
#10-32 x 7/8” Slpanhd
1
48 325P103* Scr, HXCAP 1/4-20 x 3/4”
1
49 325P104* Washer, Flat 1/4” S/S
1
50 325P109* Scr, Hxcap 1/4-20 x 3/4”
1
51 4010137
Switch, Rocker (25A-250V)
1
52 4010187 Transformer,
Stepdown
(240V/12)
53 4010190 Switch,
Momentary
1
54 4010193
PC-Board, Switch-Two Button
1
55 7000272 Thermostat,
Hi-Limit
1
56 4050229 Line
Filter
1
57 7000370
Solid State Relay
1
58 7000136
Terminal Block, 3-Pole
1
59 4060362
LED, Snap-in (Green - Ready)
1
60 4060363
LED, Snap-in (Yellow - Cooking) 1
61 4060385
LED, Snap-in (Blue - Bacon)
1
62 7000390 Control
Board
1
63 7000391
A/C Line Isolator Board
1
64 0400337 Insulation
1
65 2120111 Spacer
1
66 4050214 Thermocouple
1
67 2180111
Plastic Dispensing Bottle
1
(not
shown)
68 213K115
Spatula, Scraper and Brush Kit 1
(not
shown)
69 0011251 Heat
Sink
Assembly
1
70 0700648
Wire Set, Main (not shown)
1
71 0700655 Wire
Harness/PCB-LEDs
1
(not
shown)
72 0700656 Wire
Harness/PCB-Isoloator
BD 1
(not
shown)
73 0700657
Wire Harness/PCB-2 Button Bd 1
(not
shown)
* Available only packages of 10.
Item Part
Description
Qty.
No.
Item Part
Description
Qty.
No.
REPLACEMENT PARTS (continued)
