- 20 -
9
Slow Motion Mode button [ ] ( l 80 )
/
Zoom range button [ ] ( l 75 )
10 Photoshot button [ ] ( l 47 )
11 SET button [SET] ( l 56 , 60 , 111 , 121 )
≥ Use the SET button to select the recording functions and playback
operations, and to operate the menu screen.
≥ In this owner’s manual, the operation of the SET button is denoted as
shown below.
Example:
12 In Recording Mode: Zoom button [W/T] ( l 73 )
In Playback Mode: Volume button ( l 58 , 129 )
Zoom button [W/T] ( l 125 )
Thumbnail display switch [ / ] ( l 58 )
13 Recording start/stop button [ ] ( l 44 )
14 Menu button [MENU] ( l 60 )
15 Rear door ( l 22 , 32 )
16 Card slot
17 Battery holder
18 HDMI micro connector ( l 144 )
19 USB/AV connector ( l 25 , 144 , 153 , 201 )
≥ Use the USB cable/AV cable (only the supplied cable).
or Select using the SET button
MENU 14
9
10
11
12
19
18
17
16
15
13
HX-WA30
HX-WA3 HX-WA03
