8-14
DuraLAN Fast Ethernet NICs User’s Guide
Adding or Removing Ports
Note:
If you add or remove a port to or from a group, any existing
group or port IP address is removed automatically. Keep track of
any IP addresses you plan to use again.
1
In the Duralink64 Port Aggregation window, go to the
Configuration tab.
2
In the Group(s) field, click Create New Group, and then type
the new group name, or select the appropriate group you want
to modify.
– To add ports to the group, click the appropriate port from the
Available Adaptec Ports box, and then click Add.
– To remove ports from the group, click the appropriate port from
the Group Ports box, and then click Remove.
3
Repeat step 2 for each appropriate port.
4
To save changes, click Apply.
5
When you are finished, click OK.
6
If SNMP is not set up on the computer, you will receive the
message below. Click OK.
Figure 8-11. This message may be ignored during this installation.
