CS-1016 Rear View:
*
T
The figure shows a CS-1016 model. The only difference between it and the
other models is in the number of Port Selection Switches.
1. Daisy Chain Section
If you daisy chain units, the cables plug in here.
2. CPU Port Section
The cables that link to the computers plug in here.
3. Power Jack
The power adapter plugs in here.
4. DIP Switch
SW 1 - 5: Sets the Station No. (see the table on page 23 for details)
SW 6: Enables/Disables OSD Hot Key switching (On=Enabled:
Off=Disabled).
5. Link
Link is reserved and has no function at this time.
6. Console Port Section
If this is a first station unit, your monitor, keyboard and mouse plug in here.
7. Microphone and Speaker Jacks
Your microphone and speakers plug in here.
1 2
3 4 5 6 7
2001-01-13
CS-1004 / CS-1008 / CS-1016 User Manual 5
