Specifications
Function CS-1004 CS-1008 CS-1016
Power Consumption DC 9V 500mA
D C 9 V
600mA
D C 9 V
800mA
PC Connections
Direct 4 8 16
M a x . ( v i a
Daisy Chain)
128 256 512
Port Selection
Front Panel Switches
Hot Keys
On Screen Display
LEDs
Power 1
On Line 4 8 16
Selected 4 8 16
Connectors
Console
1 x 6 pin mini-DIN Female (PS/2 Style Mouse)
1 x 6 pin mini-DIN Female (PS/2 Style Mouse)
2 Earphone Jacks (Mic. and Speaker)
1 HDB-15 Female (std. VGA/SVGA)
CPU Ports 4 DB 25 Female
8 D B 2 5
Female
1 6 D B 2 5
Female
Daisy Chain
Ports
2 DB 25 Male/Female
Scan Interval (OSD Select) 3, 5, 10, 15, 20, 30, 40, 60 secs.
Operating Temperature 5 - 40
o
C
Storage Temperature -20 - 60
o
C
Humidity 0 - 80% RH, Noncondensing
Housing Metal
Weight 2650g 2850g 3850g
Dimensions (L x W x H)
483 x 150 x 89 mm (19"
1U)
483 x 150 x 89 mm (19"
2U)
2001-01-13
CS-1004 / CS-1008 / CS-1016 User Manual 25
