― 6 ―
Temperature & humidity
: 0℃ ∼ 40℃ (RH: 85% or less)
range
(no condensation)
Storage temperature &
: -20℃ ∼ ＋60℃ (RH: 75% or less)
humidity range
(no condensation)
Response time
: Meter reading comes within accuracy
within 3 sec. after a resistance
corresponding to the mid-scale value
and 0Ω is suddenly applied across
the measuring terminals.
(It may take time when measuring a
capacitive load.)
Insulation resistance
: at least 100MΩ/ DC1000V between
the electrical circuit and the enclosure
Withstand voltage
: AC5, 550V(50/60Hz) for 1 min. between
the electrical circuit and the enclosure
Overload protection
: The instrument operates properly
after each of the voltage shown in the
table below is applied for 10 sec.
Dimension
: approx. 105(L) x 158(W) x 70(D)mm
Weight
: approx. 520g (including batteries)
Power source
: R6P (SUM-3), AA, x 6pcs
Nominal power
: 3.5VA
Accessories
MODEL7103 Test lead with remote control switch
1 set
MODEL7081 Guard cord (Only for MODEL3315)
1 pce
MODEL7101 Flat test bar
1 pce
MODEL7131 Safety alligator clip
1 pce
MODEL8017 Extension prod
1 pce
Neck strap
1 pce
Cord case
1 pce
R6P (SUM-3), size AA
6 pcs
Instruction manual
1 pce
3315
1000V range : AC 1200V
The other ranges : AC 600V
AC 1200V
MODEL
Insulation
resistance
AC voltage
3316
All ranges : AC600V AC voltage
AC 720V
