Yokogawa PC-Based MX100 User Manual
Page 154
7-14
SM MX100-01E
7.4 Disassembling the MX112 Medium-Speed
Strain Input Module
7.4.1 Disassembling the MX112-NDI-M04
1.
Remove the terminal cover, then remove the screw.
2.
Remove the 4 latches from the left and right sides of the Bezel.
3.
Pull the Bezel in the direction of the arrow and separate the Bezel and Module
case.
Bezel
Bezel
Removed
Module case
