B3.3 side and rear views, B3.4 rs-485 configuration switches, B3.3 – Yokogawa YFGW410 User Manual
Page 27: B3.4, B3-2
B3-2
IM 01W02D01-01EN
B3.3 Side and Rear Views
Left side
Right side
Rear
Name plate
DIN rail mounting bracket
FB0303.ai
Figure B3-3 YFGW410 side and rear views
B3.4 RS-485 Configuration Switches
SW602
SW604
SW603
SW605
Top cover
Switch number
RS-485 configuration switches
Circuit board
FB0304.ai
Figure B3-4 RS-485 Configuration Switches
