Page 8

Isc = 0.7 A
Ca = 16 µF
La = 10 µH

2. Selected Associated Nonincendive Field Wiring

Apparatus shall satisfy the following:

3. If the electrical parameters of the cable are

unknown, the following values may be used:

Capacitance = 60 pF/ft
Inductive = 0.20 µH/ft

4. Nonincendive Field Wiring must be installed in

accordance with article 501.10(B) of the National
Electrical Code ANSI/NFPA 70.

5. Nonincendive Field Wiring Apparatus shall not con-

tain or be connected to another source of power.

• USB (mini B) Interface (USB2) is for temporary

connection only during maintenance and setup of
the device. Do not use, connect, or disconnect
unless area is known to be non-hazardous.
Connection or disconnection in an explosive
atmosphere could result in an explosion.

Digital Electronics Corporation

8-2-52 Nanko-higashi
Suminoe-ku, Osaka 559-0031
JAPAN
TEL: +81-(0)6-6613-3116
FAX: +81-(0)6-6613-5888
http://www.pro-face.com

The information in this document is subject to
change without notice.
Copyright © 2012.11 Digital Electronics Corporation.
All Rights Reserved.

Associated

Nonincendive

Field Wiring

Apparatus for

USB (Type A)

interface of the

GP-4100 Series

Nonincendive Field

Wiring Apparatus

Voc

≤

Vmax

Isc

≤

lmax

≥

Ci + C cable

≥

Li + L cable

Inquiry

Do you have any questions about difficulties with
your GP?
Please access our site anytime that you need
help with a solution.

http://www.pro-face.com/otasuke/

Please be aware that Digital Electronics Corpora-
tion shall not be held liable by the user for any
damages, losses, or third party claims arising
from the uses of this product.

Note
