INSTRUCTIONS AND PARTS LIST AECR-3/13/2012

Supersedes Instruction & Parts List AECR-8/3/2011

WARNING: Read instructions for proper care in handling
and operation. Use in Well Ventilated Area to remove or
trap dust. AE & AEX Compounds for External use Only!
Paasche abrasives are listed as nuisance dusts. Consult
the product label and Material Safety Data Sheet supplied
for the material being sprayed. Secure air and material
hoses wrench tight for safety and to prevent leaks.
M A X I M U M A I R P R E S S U R E 5 0 P . S . I .

AECR

Remote Feed Air Eraser
with Quart Container

OPERATING INSTRUCTIONS AND REPLACEMENT PARTS

INTRODUCTION:
AECR
Remote Feed Air Eraser with Quart Cup offers greater
freedom of movement through use of a larger abrasive
compound container which feeds abrasive by hose to the AECR
Eraser. The large container allows the operator to work longer
between refills.

The AECR Eraser is used by:

Dental professionals to improve aesthetics of castings or

obtain occlusal relationship analysis of gold castings.

Hobbyists to etch decorative glass or quartz.
Museums and Manufacturers to clean antique jewelry

and fine parts.

Lithographer to highlight halftones and erase defects

without marring the surface or leaving a smudge.

The AECR Eraser can only be used with the following abrasive:

• AEX- Fast Cutting Compound

The most popular AEX- Compound has a particle size from 85
to 25 Microns, with an average 50 Microns.

OPERATION:

1. Connect A-1/8-6MT Air Hose Assembly as follows:

a. Small coupling nut to valve casing.
b. Large coupling nut to Air Supply.

2. Connect AE-73 Hose Assembly to AE-51 Cover

Assembly. Make sure all connections are secure.

a. Small coupling nut to valve casing (#24).
b. Large coupling nut to outlet casing (#29).
c. The opposite end of the AE-73 Hose Assembly

should be attached to the AECR Eraser.

3. Fill 20SCC Quart Cup (#30) with clean dry abrasive up

to the fill line, as marked on illustration (page 2).

a. Make sure Gasket (#26) is properly placed in cover.

Screw cover tightly back onto cup.

b. To prevent leakage, do not spill any abrasive on

gasket or cup threads during assembly.

4. Regulate air pressure from 30 to 45 lbs. depending on

the speed and abrasive action desired. The higher the
pressure the faster the cutting action. Do Not Exceed
50 lbs. Air Pressure.

Paasche Airbrush Company

4311 North Normandy Avenue

Chicago, IL 60634-1395

Phone: 773-867-9191 • Fax: 773-867-9198

Website: paascheairbrush.com

E-Mail: [email protected]

Printed in the U.S.A.

5. Hold AECR Remote Feed Air Eraser between thumb

and index finger, similar to holding a pencil.

a. Move the Eraser over work surface, with the Tip

w/Carbide Insert about 1/8" to 1/2" from surface.

b. For fast aggressive work, use AEX- Abrasive at

maximum pressure of 45 lbs.

IMPORTANT ADJUSTMENTS:
If AECR Eraser should become clogged check the following:

1. Turn off air pressure, unscrew cover from cup, and

remove compound from cup. Then screw cover on cup.
Turn air on at low volume.

2. Remove Tip, clean tip by blasting it with air.
3. Blow air through shell AE-70 and AE-73 Hose Assembly

to make sure they are clear.

4. If all of the above items are clear, turn off air pressure

and remove cover. Refill container and replace cover
then turn on air at source and continue working.

AECR Remote Feed Eraser comes complete with the following:

• AECR Eraser
• A-1/8-6MT Air Hose W/MT Moisture Trap
• AE-73 Hose Assembly w/Handle & Fittings
• AE-51 Cover Assembly w/Fittings
• 7-GN Gasket
• 20SCC Quart Cup

OPTIONAL ITEMS:

• HF-592 Adapter
• HF-33 Couplers (2)
• R-75AR

NOTE: Parts are subject to wear due to nature of material

being used.

AVAILABLE COMPRESSORS
D200R
Air Compressor 1/6 HP, 110V., 60 Hz, 1.5 AMP,.7CFM@
20 psi. Delivers 30 to 40 psi operating pressure.

ETCHING COMPOUND RECOMMENDATION

COMPOUND APPROXIMATE AIR PRESSURE

CUP FILL LEVEL

AEX

1/4 TO 3/4 FULL

30 TO 45 P.S.I.

PUMICE

1/2 TO 3/4 FULL

30 TO 45 P.S.I.

STARCH

3.4 FULL

40 TO 45 P.S.I.
