3. Wiring
3.1 Basic
Structure
PERSONAL
COMPUTER
PC software
Optional
Teaching pendant
Optional
Cable length: 5 m
Host system
Relay cable
Standard cable
Robot cable
Cable length: 1 m, 3 m, 5 m
PIO
SIO
ERC actuator
(Not used)
24-VDC control/motor power supply (2 A or more)
Brake release switch
Emergency-stop/motor-power cutoff circuit
Drain wire
