INSTALLATION

ICW-IOM-2014-0410

SECTION 2

2-16

Air Flow
Safety Switch

U.L. Approved
Induced Draft Fan

Side Wall

Vent

Termination

(By Others)

Side Wall Vent
(By Others)

FIGURE 4 - TYPICAL SIDEWALL VENTING
