47-308-01 • 01/01
B A - 2 1 0 S P Bassamp Cube
with Digital Effects
TECHNICAL SPECIFICATIONS:
OUTPUT POWER RATING 220 Watts at 4 ohms @5% THD
MAX INPUT LEVELS 0dB Input: 2.00V RMS
-15dB Input: 8.00V RMS
CD Input: 7.75V RMS
LINE OUT LEVEL 1.78V RMS
HEADPHONE OUT LEVEL 900mV RMS
GAIN 41dB (input to speaker out, tones @5)
STYLE 1 = -25dB @500Hz
2 = -12dB @500Hz
3 = flat
4 = +5dB @2kHz and above
5 = -6dB @50Hz and below
LOW 40dB range @50Hz
MID 30dB range @500Hz
HIGH 40dB range @10kHz
SPEAKER SPECS (2) 10”, 100 w, 8 ohm, 2” voice coil dia., 30oz. magnet
Piezo tweeter
POWER REQUIREMENTS 120VAC, 60Hz, 320VA
100/115VAC, 50/60Hz, 320VA
230VAC, 50/60Hz, 320VA
SIZE AND WEIGHT 21” W x 21” H x 15-1/2” D; 86 lbs.
Ampeg continually develops
new products, as well as
improves existing ones. For this
reason, the specifications and
information in this manual are
subject to change without
notice.
CAUTION: THIS SPEAKER IS CAPABLE
OF PRODUCING HIGH SOUND PRES -
SURE LEVELS. CONTINUED EXPO-
SURE TO HIGH SOUND PRESSURE
LEVELS CAN CAUSE PERMANENT
HEARING IMPAIRMENT OR LOSS.
USER CAUTION IS ADVISED, AND EAR
PROTECTION RECOMMENDED IF
UNIT IS OPERATED AT HIGH VOLUME.
