AVALON RF, INC. Page 3
MX416 User’s Guide & Operating Manual
MX416-T (Transmitter)
1.1 Charging Port
The charging connector is a 4-pin size 00B LEMO connector. A
separate wall mount charger is provided thereby avoiding the need
for a cradle.
1.2 RF Output/ Antenna
The MX416 has a 50 Ohm RF output through a MCX jack. An
antenna is included for each unit.
MX416-R (Receiver)
1.3 I/O Connector
This is also a 4-pin size 00B LEMO connector. It has 2 pins for power
and speaker/audio output.
1.4 RF Input/ Antenna
This MCX jack is an rf input connector for an antenna. A short omni
whip (supplied) can be used for short distances up to a few hundred
feet or a high gain omni (or directional antenna if the application
permits) can be connected using a adaptor cable (optional).
