MX416 User’s Guide & Operating Manual
Top View
1 Antenna – MCX Connector
2 Power On/Off switch
Bottom View
3 Transmitter - Battery Charger
Connector
Receiver - I/O Connector
Front View
4 Microphone (Transmitter only)
Figure A – MX416 Controls and Connectors
