KeypadLinc Schedule Timer Owner’s Manual
Page 13 of 26
Setting the Clock in KeypadLinc Schedule Timer
1) Set KeypadLinc to Programming Mode by pressing & holding the Set button for 3 seconds
The LED will cycle between the On, A, and B buttons
2) Tap the A button to enter Clock Setup Mode
KeypadLinc will beep and the On button will begin blinking (if the clock has already been
programmed, KeypadLinc will flash the A, B, C, and D buttons to show the clock time)
3) Once the On button begins blinking continuously, tap the A, B, C, and D buttons to enter the desired
time. See Entering Time in KeypadLinc Schedule Timer.
KeypadLinc will beep with each button tap
4) Tap the On button to accept the entered time
KeypadLinc will beep and the LED will cycle between the On, A, and B buttons
5) Tap the On button to exit Clock Setup Mode
KeypadLinc will beep and the On or Off button will turn on solid based on the state of the load
Scene button LEDs will turn on solid if the scenes are activated
Programming a Timer in KeypadLinc Schedule Timer
NOTE: If the same ON or OFF timer is used for more than one scene button, the timers will activate one
minute apart from one another. For example, if you program both the A and B buttons with an OFF time
for 09:00, A will turn off at 09:00 and B will turn off at 09:01. Buttons will activate in the following order,
when applicable: On, Off, A, B, C, and D.
1) Set KeypadLinc to Programming Mode by pressing & holding the Set button for 3 seconds
The LED will cycle between the On, A, and B buttons
2) Tap the B button to enter Timer Setup Mode
KeypadLinc will beep and the LED will cycle between the On, A, B, C, and D buttons
3) Tap the Scene button you would like to program the timer into (On, A, B, C, or D)
KeypadLinc will beep and the LED will cycle between the On and Off buttons
4) Tap the A, B, C, and D buttons to enter the desired ON time. See Entering Time in KeypadLinc
Schedule Timer.
KeypadLinc will beep with each button tap
5) Tap the On button accept the ON time
KeypadLinc will beep and the B button will turn on solid while the On button begins blinking
6) Tap the A, B, C, and D buttons to enter the desired OFF time
KeypadLinc will beep with each button tap
7) Tap the Off button to accept the OFF time
KeypadLinc will beep and the B button will turn on solid while the Off button begins blinking
8) Tap the Off button to return to Programming Mode
KeypadLinc will beep and the LED will cycle between the On, A, and B buttons
9) Tap the On button to exit Programming Mode and return to normal operation
KeypadLinc will beep and the On or Off button will turn on solid based on the state of the load
Scene button LEDs will turn on solid if the scenes are activated
