7
ANC-1 INSTALLATION
Installation
The ANC-1 can be mounted on a wall using screws through the case flanges (#6 or 6mm dia. X 4) or two screws in the keyholes on the
rear (#8 or 4.5mm dia., max 9mm dia. head).
Please install the unit away from heat sources, such as vents and radiators, and in rooms with adequate ventilation. Ensure that air can
circulate freely behind, beside, and above the unit. Do not exceed the maximum ambient operating temperature of 113 degrees F (45°C).
Be aware of conditions in an enclosed rack that may cause the temperature to exceed ambient room conditions.
120mm, 4.724"
107.3mm, 4.224"
56.8mm, 2.235"
8.7mm, 0.343"
4.8mm, 0.34" dia.
9.5mm, 0.37" dia.
232.3mm, 9.146" 245mm, 9.64"
40mm, 1.575"
4.2mm, 0.166" dia., 4 places
