Remote Control Selection
To select a source device with a remote control, press the number
button that corresponds to the port it is connected to.
Alternatively, you may also cycle through the available source
devices by pushing the Port Up and Port Down buttons on the
remote control unit.
Š
Use the Port Up button to select the next available port in an
ascending order (from left to right on the front view panel).
Š
Use the Port Down button to select the next available port in a
descending order (from right to left on the front view panel).
Note: 1. The maximum range of the remote control unit is 10
meters (32 feet).
2. Aim the remote control unit at the IR receiver located on
the front panel of the HDMI Switch. For optimum
performance, make sure there is a clear line-of-sight
between the remote control unit and the IR receiver.
