2
1. Content of delivery
•
1 camera wall mount bracket
• 1 hinge element
•
1 housing base part
•
1 housing upper part
• 1
sunshield
•
1 installation material
• 1 installation manual
2. Installation oft the outdoor housing
The installation of the housing. The cable length
starting from the outside of the wall should be
mininimum 1,5 meter.
2.1. Installallation of the wall mount bracket
2.1.1. Please use the bracket as drill hole
template.
2.1.2. Then drill the holes for the camera
bracket mounting screws.
2.1.3. Route the cables through the bracket
and use the cable ties for strain relief.
2.1.4. Now fix the bracket on the wall using the
screws.
