INTEGRATED CIRCUITS INC.
-
APR9301
http://www.aplusinc.com.tw
Page / 10 VER2.1
8
Table 5 APR9301 Bonding Pad Coordinates :
Pin
Pin Name
X – Axis (Note)
Y – Axis (Note)
/CE Chip
Enable -2496.2
1565.8
OscR
Oscillator Frequency-Setting
Resistor
-2459.55 729.8
NU1 Connect
to
Ground -1808.45 -1496.1
VSSD Digital
Ground
Supply -1564.05 -1572
VSSA
Analog Ground Supply -1384.05 -1548.7
VSSA
Analog Ground Supply -1204.35 -1477.1
SP+
Non-Inverting Speaker Output
-707.15
-1390
SP- Inverting
Speaker
Output 479.15
-1389.9
VCCA
Analog Power Supply
976.45
-1492
VCCA
Analog Power Supply
1190.4
-1523.7
MinIn Microphone
Input 1619.45 -1551.4
MicRef Microphone
Reference Input
2035.45
-1551.4
AGC Automatic
Gain
Control 2487.45 -1551.4
AnaIn
Analog Signal Input
2487.45
-1049.9
AnaOut
Analog Signal Output
2487.45
-648.9
/PlayE Edge-Activated
Playback
2493.65
1371.1
/LED LED
Output
1430.7
1565.8
VSSD Connect
to
Ground
865.75 1565.8
/RecL Level-Activated
Record
258.15
1565.8
VCCD Digital
Power
Supply
-229.4 1579.05
VCCD Digital
Power
Supply
-510.8
1541.6
Note: With respect to die center(um)
