Absolute Maximum Ratings
Stresses greater than those listed in Table 2 may cause permanent damage to the
device. These specifications represent a stress rating only. Operation of the device at
these or any other conditions above those specified in the recommended DC
Characteristics or recommended Analog Characteristics of this specification is not
implied. Operation of the device at maximum conditions for extended periods may affect
reliability.
Table 2 Absolute Maximum Ratings.
Item Symbol Condition Min Max Unit
Power Supply Voltage Vcc TA = 25℃ 4.5 6.5 V
Input Voltage VIN1 TA = 25℃ -0.3 Vcc +0.3 V
Input Voltage VIN2 ︱ IIN︱ <20 mA -1.0 Vcc +1.0 V
Storage Temperature TSTG -- -65 150 ℃
Temperature Under Bias TBS -- -65 125 ℃
Lead Temperature TLD <10s -- 300 ℃
Table 3 DC Characteristics ( Note 1 )
Item Symbol Condition Mm Typ Max Unit
Input High Voltage VIH -- 0.8 x Vcc -- -- V
Input Low Voltage VIL -- -- -- 0.8 V
Output High Voltage VOH IOL = -1 .6mA 2.4 -- -- V
Output Low Voltage VOL IOL = 4.0mA -- -- 0.45 V
Input Leakage Current IIH VIH = Vcc -- -- 1.0 uA
Input Leakage Current IIL VIL = Vss( Note 2 ) -1.0 -- -- uA
Output Tristate Leakage Current Ioz VOUT = VCC or VOUT=VSS -1.0 -- 1.0 uA
Operating Current Consumption Icc Internal Clock, No Load -- 25 -- mA
Standby Current Consumption lccs No Load -- 1.0 -- uA
