DS2165/DS2165Q
041295 16/17
DS2165 16/24/32KBPS ADPCM PROCESSOR 24–PIN DIP
A
B
C
E
F
G
H
J
K
D
1
PKG 24-PIN
DIM MIN MAX
A IN.
MM
1.150
29.21 1.260
32.00
B IN.
MM
0.250
6.35 0.270
6.86
C IN.
MM
0.120
3.05 0.140
3.56
D IN.
MM
0.300
7.62 0.325
8.26
E IN.
MM
0.015
0.38 0.040
1.02
F IN.
MM
0.125
3.18 0.135
3.48
G IN.
MM
0.090
2.23 0.110
2.79
H IN
MM
0.320
8.13 0.370
9.40
J IN
MM
0.008
0.20 0.012
0.30
K IN.
MM
0.015
0.38 0.022
0.56
