MAX7445
4-Channel Video Reconstruction Filter
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V
CC
= +5V ±5%, C
L
= 0 to 20pF, R
L
= 75
Ω to GND for DC-coupled load, R
L
= 75
Ω to V
CC
/ 2 for AC-coupled load, C
IN_
= 0.1µF,
GAIN = GND (+6dB) or V
CC
(+9.5dB), T
A
= T
MIN
to T
MAX
, unless otherwise noted. Typical values are at V
CC
= +5V, T
A
= +25
°C.)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V
CC
to GND ...........................................................................+6V
All Other Pins to GND.................................-0.3V to (V
CC
+ 0.3V)
Maximum Current into Any Pin Except V
CC
and GND .....±50mA
Continuous Power Dissipation (T
A
= +70°C)
TSSOP-EP (derate 20.8mW/°C above +70°C) ...........1667mW
Operating Temperature Range ...........................-40°C to +85°C
Storage Temperature Range .............................-65°C to +150°C
Junction Temperature ......................................................+150°C
Lead Temperature (soldering, 10s) .................................+300°C
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Channel without
boost (see Table 2)
-0.75
+0.15
+0.75
Passband Response
f = 100kHz to 5MHz,
relative to 100kHz
Channel with boost
(see Table 2)
+0.9
+1.2
+1.5
dB
Stopband Attenuation
A
SB
f
≥ 27MHz
39
43
dB
Gain = +6dB,
+9.5dB
0.15
0.50
Differential Gain
dG
5-step modulated
staircase
Gain = +12dB
0.25
0.90
%
Gain = +6dB,
+9.5dB
0.15
0.50
Differential Phase
d
θ
5-step modulated
staircase
Gain = +12dB
0.15
0.60
Degrees
Signal-to-Noise Ratio
SNR
Peak signal (2V
P-P
) to
RMS noise,
f = 100Hz to 50MHz
Gain = +6dB,
+9.5dB, +12dB
69
75
dB
Channel without
boost (see Table 2)
11
20
Group Delay Deviation
∆t
g
Deviation from 100kHz
to 4.1MHz
Channel with boost
(see Table 2)
17
30
ns
Line-Time Distortion
H
DIST
18µs, 100 IRE bar
0.3
%
Field-Time Distortion
V
DIST
130 lines, 18µs, 100 IRE bar
0.5
%
Clamp Settling Time
t
CLAMP
To ±1%
100
Lines
Channel A
0.6
0.9
1.1
SELECT = GND
Channels B, C, D
1.1
1.5
1.8
Channels A, B, D
0.6
0.9
1.1
SELECT = V
CC
Channel C
1.25
1.6
1.95
Channels A, D
0.6
0.9
1.1
Output DC Clamp Level
SELECT = floating
Channels B, C
1.1
1.5
1.8
V
Low-Frequency Gain Accuracy
A
V
f = 100kHz, relative to a gain of +6dB
-3
+3
%
Low-Frequency Gain Matching
A
V ( M ATC H )
Low-frequency channel-to-channel matching,
f = 100kHz
4
%
