MAX9508
Video Filter Amplifier with SmartSleep and
Bidirectional Video Support
_______________________________________________________________________________________ 5
Note 1: All devices are 100% production tested at T A = +25°C. Specifications over temperature limits are guaranteed by design.
Note 2: Specified current is an average over time.
AC ELECTRICAL CHARACTERISTICS (continued)
(V DD = V SHDN = 3.3V, V SMARTSLEEP = V INT/EXT = GND = 0V, R L = 150Ω to GND. T A = T MIN to T MAX , unless otherwise noted. Typical
values are at T A = +25°C.) (Note 1)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Nonlinearity 5-step staircase 0.1 %
Interchannel Timing
Error Difference in time between the 50% point of the output
signals, YOUT to COUT
0.2 ns
Group Delay
Distortion
100kHz ≤ f ≤ 5MHz, inputs are 1V
P-P 10 ns
Interchannel Group
Delay Distortion Error
Inputs are 1V P-P 2 ns
Peak Signal to RMS
Noise
100kHz ≤ f ≤ 5MHz, inputs are 1V
P-P 67 dB
Power-Supply
Rejection Ratio
f = 100kHz, 200mV P-P , input referred 43 dB
Output Impedance f = 5MHz 6 Ω
Enable Time
YIN = 1V, output settled to within 1% of the final voltage,
R
L = 150 Ω to GND
13 µs
Disable Time
YIN = 1V, output settled to within 1% of the final voltage,
R
L = 150 Ω to GND
1.1 µs
CROSSTALK
All Hostile Output
Crosstalk
f = 4.43MHz -70 dB
All Hostile Input
Crosstalk f = 4.43MHz, SHDN = GND,
input termination resistors are 75
Ω
-69 dB
