Features
1
2
3
4
5
6
7
3
1 Door Handle
Ergonomically designed for one handed operation.
2 Unit Serial Number
Located on the lower left hand side and back of the
oven.
3 Air Filters
The oven has two air filters. Each are located on
the lower sides of the oven. To remove, simply slide
out.
4 Display
Display provides user interface.
5 ON/OFF Pad
Use to turn on and shut oven off.
6 Keypad
Use for time input, programmed pads and data
input.
7 USB Port / Protective Cover
The oven is equipped with an USB Data Port. Use
with standard flash drives.
To program the oven using standard flash drive:
Oven must be in Off mode (Preheat must be OFF)
1. Remove protective cover from bottom of keypad.
2. Insert the flash drive into the slot located below the keypad.
3. From Off, press and hold the “2” pad to go to “User Options”.
4. Go to Option #17 by pressing “Back ” or repeatedly pressing “Enter ”
5. Select the desired operation by highlighting “Transfer card to oven ” or “Transfer oven
to flash drive ” with the Scroll Up or Scroll Down keypad .
*Important Note: After inserting flash drive in USB port wait at least 6 seconds before proceeding to Step 6.
6. Press the “Program
” pad to begin the transfer (The screen will indicate”TRANSFERRING” and indicate
“DONE” wait 15 seconds then transfer is complete.) *Important Note: If you do not wait 15 seconds when new
upload is attempted the screen will indicate “ NOT AXP CARD”.
7. Remove flash drive and close the protective cover.
