Preliminary
VS-GT50TP60N
www.vishay.com
Vishay Semiconductors
Revision: 22-Dec-11
2
Document Number: 94666
For technical questions within your region:
,
,
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
IGBT ELECTRICAL SPECIFICATIONS (T
C
= 25 °C unless otherwise noted)
PARAMETER
SYMBOL
TEST CONDITIONS MIN.
TYP.
MAX.
UNITS
Collector to emitter breakdown voltage
V
(BR)CES
T
J
= 25 °C
600
-
-
V
Collector to emitter saturation voltage
V
CE(sat)
V
GE
= 15 V, I
C
= 50 A, T
J
= 25 °C
-
1.65
2.10
V
GE
= 15 V, I
C
= 50 A, T
J
= 175 °C
-
2.05
-
Gate to emitter threshold voltage
V
GE(th)
V
CE
= V
GE
, I
C
= 1.4 mA, T
J
= 25 °C
4.0
4.9
6.5
Collector cut-off current
I
CES
V
CE
= V
CES
, V
GE
= 0 V, T
J
= 25 °C
-
-
1.0
mA
Gate to emitter leakage current
I
GES
V
GE
= V
GES
, V
CE
= 0 V, T
J
= 25 °C
-
-
400
nA
SWITCHING CHARACTERISTICS
PARAMETER
SYMBOL
TEST CONDITIONS MIN.
TYP.
MAX.
UNITS
Turn-on delay time
t
d(on)
V
CC
= 300 V, I
C
= 50 A, R
g
= 3.3
,
V
GE
= ± 15 V, T
J
= 25 °C
-
58
-
ns
Rise time
t
r
-
31
-
Turn-off delay time
t
d(off)
-
80
-
Fall time
t
f
-
100
-
Turn-on switching loss
E
on
-
0.41
-
mJ
Turn-off switching loss
E
off
-
0.42
-
Turn-on delay time
t
d(on)
V
CC
= 300 V, I
C
= 50 A, R
g
= 3.3
,
V
GE
= ± 15 V, T
J
= 125 °C
-
64
-
ns
Rise time
t
r
-
37
-
Turn-off delay time
t
d(off)
-
90
-
Fall time
t
f
-
117
-
Turn-on switching loss
E
on
-
0.69
-
mJ
Turn-off switching loss
E
off
-
0.69
-
Input capacitance
C
ies
V
GE
= 0 V, V
CE
= 30 V, f = 1.0 MHz
-
3.03
-
nF
Output capacitance
C
oes
-
0.25
-
Reverse transfer capacitance
C
res
-
0.09
-
SC data
I
SC
t
p
5 μs, V
GE
= 15 V, T
J
= 125 °C,
V
CC
= 360 V, V
CEM
600 V
-
450
-
A
Stray inductance
L
CE
-
-
30
nH
Module lead resistance, terminal to chip
R
CC’+EE’
-
0.75
-
m
DIODE ELECTRICAL SPECIFICATIONS (T
C
= 25 °C unless otherwise noted)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN.
TYP.
MAX.
UNITS
Forward voltage
V
F
I
F
= 50 A
T
J
= 25 °C
-
1.35
1.75
V
T
J
= 125 °C
-
1.37
-
Reverse recovery charge
Q
rr
I
F
= 50 A, V
R
= 300 V,
R
G
= 3.3
V
GE
= - 15 V
T
J
= 25 °C
-
2.3
-
μC
T
J
= 125 °C
-
4.3
-
Peak reverse recovery current
I
rr
T
J
= 25 °C
-
33
-
A
T
J
= 125 °C
-
58
-
Reverse recovery energy
E
rec
T
J
= 25 °C
-
0.56
-
mJ
T
J
= 125 °C
-
1.11
-
