18 Supporting frame
19 Fastening kit
20 Limit bolt
21 Locking plate
22 Wing nut
23 Button for releasing lever 24
24 Lever for locking the attachment set
25 Stop
26 Movable nut
27 Nut for adjustment of lock 9
28 Nut for adjustment of limit bolt 20
29 Adjustment screw for limit bolt 20
Accessories shown or described are not part of the standard deliv-
ery scope of the product. A complete overview of accessories can
be found in our accessories program.
Technical Data
Assembly
Delivery Scope
Please also observe the representation of
the delivery scope at the beginning of the op-
erating instructions.
Before assembling the saw stand, check if all
parts listed below are provided:
Additionally required tools (not in delivery scope):
– Phillips screwdriver
– Open-end spanner (10 mm, 8 mm, 6 mm)
– Adjustable spanner
Assembling the Mobile Stand Base
– Carefully remove all parts included in the delivery from
their packaging.
– Remove all packaging material. (e. g. cable ties, etc.)
– For assembly, follow figures A – E. Also observe the follow-
ing notes.
For Fig. B:
The wheels are marked for easier assembly (“R” for right
wheel, “L” for left wheel).
Note: Do not over-tighten the nuts. Parts bolted together
must move freely.
For Fig. D:
Observe the correct assembly direction of supporting frame
18, which is indicated by the marks “R” and “L” matching the
wheels.
Note: Do not over-tighten the nuts. Parts bolted together
must move freely.
For Fig. E1:
In this assembly step, the saw stand 2 is bolted together with
the supporting frame rest 18 and the upper frame rest 13.
– Set both rest so that the lateral recesses in the rests face
towards the handle.
– While bolting the saw stand together, take care that the
support 8 is always in the fixture of the bottom frame 17.
Note: Only hand-tighten the nuts at first. After all eight bolts
are correctly positioned, they can be firmly tightened.
For Fig. E2:
Note: Do not over-tighten the nuts. Parts bolted together
must move freely.
Saw stand GTA 2500 W
Article number 3 601 M12 102
Length of saw stand without
table extension mm 1044
Length of saw stand with table
extension mm 2510
Height of saw stand mm 947
Max. carrying capacity
(power tool + workpiece)
– Attachment set kg 180
Max. carrying capacity
(power tool + workpiece)
with table extension
– Attachment set
– Per table extension
kg
kg
130
25
Weight according to
EPTA-Procedure 01/2003 kg 32.2
No. Designation Quantity
1 Attachment set 2
2 Saw stand with support 8 1
13 Upper frame
with lock 3 1
17 Bottom frame 1
14 Foot lever 1
15
16
Wheel “L”
Wheel “R”
1
1
18 Supporting frame 1
19 Fastening kit
consisting of:
– Hexagon bolt
M10 x 100
M10 x 55
M10 x 50 (self-locking)
M8 x 45
M6 x 45
– Phillips screw
M8 x 50
– Washer
M10 x 29 mm
M10
M8
M6
– Lock nut
M10
M8
M6
4
1
2
4
8
4
2
10
4
8
5
4
8
No. Designation Quantity
