Safety Notes
General Safety Rules
Read all warning notes and instructions en-
closed with the saw stand and the power tool
to be mounted. Failure to follow the warnings
and instructions may result in electric shock,
fire and/or serious injury.
Safety Warnings for Saw Stands
f Pull the plug from the mains receptacle and/or remove
the battery from the power tool before making adjust-
ments on the tool or changing tool accessories. Unin-
tentional switching on of the power tool is the cause of
many accidents.
f Assemble the saw stand in the proper manner before
mounting the power tool. Proper assembly is important
to prevent the risk of a collapse of the saw stand.
f Attach the power tool securely to the saw stand before
using it. Slipping off of the power tool on the saw stand
can lead to loss of control.
f Place the saw stand on a firm, level and horizontal sur-
face. If the saw stand can slip off or wobbles, the power
tool or the workpiece cannot be uniformly and securely
guided.
f Do not overload the saw stand and do not use it as a lad-
der or scaffolding. Overloading or standing on the saw
stand can lead to the upward shifting of the centre of grav-
ity of the stand and its tipping over.
f When working or transporting, take care that all bolts
and connecting elements are firmly tightened. The at-
tachment sets for the power tool must always be firmly
locked. Loose connections can lead to instability and inex-
act sawing.
f Mount and dismount the power tool only when it is in
the transport position (for instructions on the trans-
port position, also see the operating instructions of the
respective power tool). Otherwise, the power tool can
have such an unfavourable centre of gravity that it cannot
be held securely.
f When the power tool is mounted to the attachment set,
operate it exclusively on the saw stand. Without the saw
stand, the attachment set with the power tool does not
stand securely and can tip over.
f Ensure that long and heavy workpieces do not affect
the equilibrium of the saw stand. Long and/or heavy
workpieces must be supported at the free end.
f Keep your fingers clear of the hinge points while push-
ing the saw stand together or pulling it apart. Danger of
fingers being crushed or contused.
Symbols
The following symbols can be important for the operation of
your saw stand. Please memorise the symbols and their
meanings. The correct interpretation of the symbols helps
you operate the saw stand better and more secure.
Product Description and Specifica-
tions
Intended Use
The saw stand is intended exclusively for mounting the follow-
ing stationary Bosch saws (as of 2012.08):
Together with the power tool, the saw stand is intended for
the cutting to length of boards and profiles.
Product Features
The numbering of the product features refers to the illustra-
tion of the saw stand on the graphics pages.
1 Attachment set
2 Saw stand with support 8
3 Lock for the wheels 15/16
4 Locking knob of the table extension 5
5 Table extension
6 Handle
7 Height-adjustable leg
8 Support of saw stand
9 Lock of support 8
10 Locking knob of the workpiece support 12
11 Material stop
12 Workpiece support
13 Upper frame with lock 3
14 Foot lever
15 Wheel “L”
16 Wheel “R”
17 Bottom frame
Symbol Meaning
The maximum carrying capacity (pow-
er tool + workpiece) of the saw stand
is 180 kg.
– GCM 8 S 3 601 L16 0..
– GCM 8 SJ 3 601 L16 2..
– GCM 800 S 3 601 L16 1..
– GCM 10 0 601 B20 0..
– GCM 10 J
GCM 10 M
3 601 M20 2..
– GCM 10 S 0 601 B20 5..
– GCM 10 SD 0 601 B22 5..
– GCM 12 0 601 B21 0..
– GCM 12 GDL 3 601 M23 6..
– GCM 12 SD 0 601 B23 5..
– GTM 12 3 601 M15 0..
180
kg
