12.6. Modification (Bit) bConfirmPIN Bit1=1 Data Structure Error
Checking
Check points in implementing the PIN Modification Data Structure:
• SpePINLen + SpeOffsetNew must equal to Lc
• SpeOffsetNew >= SpeOffsetOld + SpePINLen
• SpePINPos must be equal or larger than SpePINLenPos + SpePINSize
• SpePINLen – SpePINPos must be larger or equal to SpePinMax (if BCD, need multiple 4)
• SpePinMax must be equal or larger than SpePinMin
• SpePinMax cannot be larger than 16 digits because LCD one row only have 16 digits
• PinMin must be equal or larger than 1
12.7. Modification (Byte) bConfirmPIN Bit1=1
bConfirmPIN Bit1 = 1
(Current/Old PIN entry requested)
System unit is byte.
APDU Command SpeOffsetOld Offset SpePINPos
SpePINLe
n
APDU Header APDU
Lc
Maybe not Offset SpePINPos Old PIN
CLA INS P1 P2 Lc Exist
Offset
SpePINLenPos SpePINSize
Not used
field
Old PIN
SpeOffsetNew Offset SpePINPos SpePINLen
Maybe not Offset SpePINPos New PIN
Exists
Offset
SpePINLenPos
SpePINSize Not used field New PIN
12.8. Modification (Byte) bConfirmPIN Bit1=1 Data Structure Error
Checking
Check points in implementing the PIN Modification Data Structure:
• SpePINLen + SpeOffsetNew + SpePINPos must equal to Lc
• SpeOffsetNew >= SpeOffsetOld + SpePINPos + SpePINLen
• SpePINPos must be equal or larger than SpePINLenPos + SpePINSize
SpeOffsetNew SpePINLen
Maybe not Offset SpePINPos New PIN
Exist
Offset
SpePINLenPos
SpePINSize Not used field New PIN
