ACR83 – Reference Manual [email protected]
Version 1.05 www.acs.com.hk
Page 19 of 49
11.4. Verification Example 2
System unit is bit.
abPINApdu = 00 20 00 01 08 57 A5 30 30 30 30 30 30h
After Lc (08h), the first 11 bits (01010111 101) is control character.
bmFormatString=59h
SpePinPos=11 bits because bmFormatString bit 7 = 0
SpeLeftRight=Left
SpePINTyp=BCD
bmPINBlockString=48h
SpePINSize=4 bits
SpePINLen=8 bytes
bmPINLengthFormat=06h
SpePINLenPos=6 bits
wPINMaxExtraDigit=0108h
SpePinMax=08h
SpePinMin=01h
PIN Input = 1 2 3 4 5
Command Header SpePINLen
APDU Command
Header
APDU
Length
Offset SpePINPos 7 bits PIN
00 20 00 01 08 Offset 6 bits
SpePINSize
(4bits)
Not used field/may not
exist
PIN
00 20 00 01 08
010101 11
101
Input 5 digits
Offset 6 bit relative to
Lc
PIN
00 20 00 01 08 010101 0101 (bits) 1 (bit)= 01010111 10 1 PIN
00 20 00 01 08 010101 01 01 1 ( 0101 replace original 010101 11 10 1) PIN
How about the the PIN management?
Because it is Left and BCD arrangement.
PIN (bits)
Original
0 0101 0011 0000 0011 0000 0011 0000 0011 0000 0011
0000 0011 0000
Input 12 34 5 (change to
bit format)
0001 0010 0011 0100 0101
Original
0 0101 0011 0000 0011 000 0 0011 0000 0011 0000 0011
0000 0011 0000
