MKCP1613/1624/3213/3224

1U rackmount Matrix Cat6 IP KVM Switch

< 1.3 > IP, Remote & Local console connection

CAT 5 / 6 cable

max. 100m

Network device

hub or router

CAT 5 / 6 cable

max. 150m

Receiver

Remote

USB console

Local

2

USB

console

Remote

Cat6

Console 1

1

CAT 5 / 6 cable

max. 100m

Network device

hub or router
