7
**Call 1‑800‑NO‑BELTS for warranty details.
WHIRLPOOL BRAND
COMMERCIAL DRYERS
FRONT LOCK READY
Factory installed lock
blank provides a visual
vandalism deterrent.
To further discourage theft, order
optional front panel lock assembly
(part #358290) for the added
security of tying the front and top
panels together.
1 ⁄
3
HP MOTOR
1 ⁄
3
HP motor with overload protection.
THERMOSTAT
Single operating thermostat for simple
accurate temperature control.
IMPROVED
AIRFLOW SYSTEM
Whirlpool ®
commercial dryers
have a new Blower
Housing Wave Insert to increase air
velocity up to 10%. This increases
efficiency, heating element lifespan,
and improves fabric care.*
*Results per Whirlpool dryer testing conducted 7/03–8/04
LARGE CAPACITY METERCASE
Larger coinbox for reduced collections.
Accepts coin slides, coin drops and
card readers.
LARGE 7.4 CU. FT.
DRUM CAPACITY
The increased capacity
allows for large loads
of clothes to tumble and spread,
saving you and your customers
drying time and expense.
LARGE LINT FILTER
Pull‑out, 84 square inch
lint filter.
4-WAY VENTING
4-Way venting from left or right side,
back or bottom.
SIDE SWING DOOR
For convenient access, the
wide-opening side-swing
door can be opened a
full 180°.
RUST PROOF SCREWS
Rust Proof Stainless
Steel Torx
® control
panel screws give your
machines added security
and service life.
Featuring Mechanical Controls
To Locate a Distributor Near You, Please Visit www.whirlpoolcommerciallaundry.com/distributor, or call 1-800-NO-BELTS
CEM2760TQ
— 27" Electric Dryer
CGM2761TQ
— 27" Gas Dryer
with Metercase
Machine Accepts the Following Payment
Systems (not included):
- Coin Slide
- Retrofit Coin Drop
- Retrofit Card Reader
- OPL Push-to-Start Kit (No Coins Needed)
• Large 7.4 Cu. Ft. Drum Capacity
• Push Button Controls
• 3 Cycles: Regular/Heavy (High Heat),
Permanent Press (Medium Heat) and
Knits/Delicates (Low Heat)
• Large, Removable, Door‑Mounted Lint
Screen (84 Sq. In.)
• 180° Wide‑Opening Side‑Swing Door
• Porcelain Top, Powdered Paint Cabinet
• Front‑Service Accessibility
• Four‑Way, Multi‑Vent Options
(Back, Bottom and Sides)
• Element Rated at 5600 Watts 240‑Volt
• Gas Model Features a 22K BTU Burner
• Motor:
1 ⁄
3
‑HP with Built‑In Overload
Protector; Centrifugal Switch Turns Off
Heating Element When Motor Stops
• Easy‑to‑Follow Console Instructions
• 3 Year Limited Parts Only Warranty
**
• Money Acceptors Sold Separately. See Page 10
for Easy Ordering Details
COMMERCIAL DRYERS
