Winegard TRAVELNET TN2300-DV User Manual
Page 2
Ver. 1.6
8/3/2009
- 2 -
Important
DO NOT CONNECT YOUR TN2300-DV SERIES TO A WALL
JACK IF YOU HAVE OUTSIDE SERVICE (I.E., A DIAL TONE)
AT YOUR WALL JACK. Your TN2300-DV SERIES will not
function properly and may become damaged if outside phone
service has not been disconnected.
2.
If desired, connect your TN2300-DV SERIES’ other phone (RJ11) jack to
a telephone using a standard telephone cord - see Figure 1
3.
Connect additional phones, to any available wall jacks.
Figure 2 (phone not included)
Using the TN2300-DV Series
Once you have installed and activated your TN2300-DV SERIES, you’ll be
ready to make and receive calls, set up voicemail, and send and receive
faxes. This section explains how to use the features of the TN2300-DV
SERIES for all your communications.
Making Calls
To make a call:
1.
Pick up the telephone handset. (The phone is now “off-hook.”)
