OVEN PARTS
2
For Models:GMC275PRB00, GMC275PRQ00, GMC275PRT00, GMC275PRS00
(Black) (White) (Biscuit) (S.Steel)
8186314
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1
Literature Parts
8303655 Installation
Instructions
8303649 Use & Care Guide
(Oven)
8303650 Use & Care Guide
(Microwave)
8302010 Tech Sheet
3191638 Safer Cooking Tips
9759133 Safer Cooking Tips
2
Trim, Side
8302927 RH Black
8302929 RH White
8302931 RH Biscuit
8303217 RH S.Steel
8302928 LH Black
8302930 LH White
8302932 LH Biscuit
8303218 LH S.Steel
Screw
8281236 Black Model
4449041 White
694091 Biscuit Model
4
4448520 Bumper, Door
6
4452490 Spacer, Foam
7
4455864 Top Chassis
4449809 Screw
8
Hinge Receiver
4455605 Left Hand
4455606 Right Hand
9
4452158 Tube, Vent
3196176 Screw
10
4452165 Lens,Light
11
4452368 Oven Light Assy
12
4452166 Bulb,Light
13
8300791 Bracket, Combo
14
4455611 Frame, Front
4449040 Screw
15
4455381 Gasket, Door
18
4452152 Bracket, Mounting
19
4451477 Support, Insulation
4449809 Screw
20
4451605 Cap, Spacer
21
Rail, Side
8303117 Right Side
8303118 Left Side
4448444 Grommet
4449154 Screw
25
4455641 Side, Chassis
(R.H. & L.H.)
4449809 Screw
26
4452233 Back, Chassis
4449809 Screw
27
Liner, Oven
(Not serviceable)
29
4455636 Sensor
4449154 Screw
30
4449845 Bracket, Support
4449809 Screw
32
8300154 Insulation,
Bottom Vent
33
9760676 Deflector, Vent
4449809 Screw
34
4451666 Vent, Center
4450038 Screw
37
9759243 Thermostat (TOD)
(Temp.) SPST
4449809 Screw
43
4455529 Base, Chassis
4449809 Screw
49
4448933 Retainer, Gasket
4449154 Screw
50
4451747 Cover, Back
4449809 Screw
51
Trim, Bottom
8302937 Black Model
8302938 White Model
8302939 Biscuit Model
8302940 S.Steel
3400832 Screw
52
8303503 Vent, Control
53
4451755 Chassis, Back
4452260 Spacer, Foam
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
4449315 Insulation, Wrap
4450364 Insulation, Back
