SCANTEAM 6920 User’s Guide

Output Data Format

Note:

See DIP Switch Feature Selection chart on page 8 for factory
default settings.

Single Track:

{PREFIX} {SS} {ES} {SUFFIX} {CARRIAGE RETURN}

Dual Track:

Track 2 data follows track 1 data or precedes track 3 data.

{PREFIX} {SS} {ES} {SUFFIX} {CARRIAGE RETURN}

Triple Track:

Track 1 data followed by track 2 data, and then track 3 data.

{PREFIX} {SS} {ES} {SUFFIX} {CARRIAGE RETURN}

Where:

SS = Start sentinel

Track 1 for ISO, CA DMV, AAMVA

;

Track 2 for ISO, CA DMV, AAMVA

;

Track 3 for ISO

Track 3 for AAMVA

Track 3 for CA DMV

ES = End sentinel

Tracks 1, 2, 3 for ISO, CA DMV, AAMVA

ISO = International Standards Organization (ISO # 7811)
CA DMV = California Department of Motor Vehicles
AAMVA = American Association of Motor Vehicle Administrators

Data characters in braces, “{ },”and not in boldface are optional.
