D. Technical specifications
- System
CPU: Trimedia PNX1300
RAM: 8MB SDRAM
ROM: 2MB FLASH ROM
- Networking
Protocol
TCP/IP, HTTP, SMTP, FTP, Telnet, NTP, DNS, DHCP,
DDNS and UPnP
Physical
10BaseT Ethernet or 100BaseT Fast Ethernet
- Video
Algorithm supported
MPEG4(short header mode)
Features
Adjustable image size, quality and bit rate
Timestamp and text overlay
3 motion detection windows
Resolution
Up to 30/25 frames at 160x120
Up to 30/25 frames at 320x240
Up to 10 frames at 640x480
- Camera Specification
1/4 inch color CMOS sensor
640x480
1.5Lux/F2.0
AGC, AWB, AES
Electronic shutter: 1/60 ~ 1/15000 second
- Lens
Standard CS mount type lens, 4.0mm, F2.0
- Audio
24Kbps
Supporting audio mute
- Microphone
Omni-directional
Frequency: 50 – 16000Hz
S/N ratio: more than 60dB
- General I/O
1 sensor input(max. 12VDC 50mA)
1 relay output(max. 24VDC 1A, 125VAC 0.5A)
- LED indicator
Dual color status indicator
- Dimension
138mm(L) * 89mm(W) * 57mm(H)
- Weight
NET. 219g
- Power
Consumption: near 3.96W
Universal switching power supply included
Input: 100-240VAC, 50/60Hz, 0.4A
Output: 12VDC, 1.5A
- Operating Environment
Temperature: 0-50°C/32-122°F
Humidity: 95%RH
- EMI & Safety
CE, FCC
- Viewing system requirement
Operating system
Microsoft Windows 98/SE/ME/2000/XP
Browser
Internet Explorer 5.x or above
