108 - User's Manual
win_i <0~2>_top 0 ~ 240 4/4 Top coordinate of window position.
win_i <0~2>_width 0 ~ 320 4/4 Width of motion detection window.
win_i<0~2>_height 0 ~ 240 4/4 Height of motion detection window.
win_i<0~2>_objsize 0 ~ 100 4/4 Percent of motion detection window.
win_i<0~2>_sensitivity 0 ~ 100 4/4 Sensitivity of motion detection window.
Group: motion_ c<0~(n-1)>_profile_i<0~(m-1)> for n channel, m motion profile product
(capability_ nmotionprofile > 0)
NAME VALUE SECURITY
(get/set)
DESCRIPTION
enable 4/4 enable motion detection
policy day,
night,
schedule
4/4 When the condition match the policy, use this
profile
begintime hh:mm 4/4 If choose “schedule” mode as profile policy, the
begin time of this profile when enabled
endtime hh:mm 4/4 If choose “schedule” mode as profile policy, the
end time of this profile when enabled
win_i<0~2>_enable < ٛ oolean> 4/4 enable motion window 1~3
win_i <0~2>_name string[14] 4/4 name of motion window 1~3
win_i <0~2>_left 0 ~ 320 4/4 Left coordinate of window position.
win_i <0~2>_top 0 ~ 240 4/4 Top coordinate of window position.
win_i <0~2>_width 0 ~ 320 4/4 Width of motion detection window.
win_i<0~2>_height 0 ~ 240 4/4 Height of motion detection window.
win_i<0~2>_objsize 0 ~ 100 4/4 Percent of motion detection window.
win_i<0~2>_sensitivity 0 ~ 100 4/4 Sensitivity of motion detection window.
Group: tampering_c<0~(n-1)> for n channel,
NAME VALUE SECURITY
(get/set)
DESCRIPTION
enable 4/4 Enable or disable camera tampering detection
threshold 0 ~ 255 4/4 The sensitivity to judge if camera has been
tampered
0: lowest sensitivity
255: highest sensitivity
duration 10 ~ 600 4/4 Judge camera has been tampered if exceeding
this duration
