AIR FOR COMBUSTION AND VENTILATION
CONTINUED
V V V V Ventilation Air Fr entilation Air Fr entilation Air Fr entilation Air Fr entilation Air From Outdoor om Outdoor om Outdoor om Outdoor om Outdoors s s s s
Provide extra fresh air by using ventilation grills or ducts. You must provide two permanent
openings: one within 12" of the ceiling and one within 12" of the floor. Connect these items
directly to the outdoors or spaces open to the outdoors. These spaces include attics and
crawl spaces. (
See Figure 2 )
IMPORTANT: Do not provide openings for inlet or outlet air into attic if attic has a thermostat-
controlled power vent. Heated air entering the attic will activate the power vent.
W W W W WARNING ARNING ARNING ARNING ARNING
Maintain the minimum clearances. If you can, provide greater clearances from Maintain the minimum clearances. If you can, provide greater clearances from Maintain the minimum clearances. If you can, provide greater clearances from Maintain the minimum clearances. If you can, provide greater clearances from Maintain the minimum clearances. If you can, provide greater clearances from
floor
floor floor floor floor,,,,, ceiling, ceiling, ceiling, ceiling, ceiling, and adjoining wall. and adjoining wall. and adjoining wall. and adjoining wall. and adjoining wall.
INST INST INST INST INSTALLA ALLA ALLA ALLA ALLATION CLEARANCES TION CLEARANCES TION CLEARANCES TION CLEARANCES TION CLEARANCES
Carefully follow the instructions below. This will ensure safe installation.
Minim Minim Minim Minim Minimum um um um um W W W W Wall and Ceiling Clearances ( all and Ceiling Clearances ( all and Ceiling Clearances ( all and Ceiling Clearances ( all and Ceiling Clearances ( see Figure 3 see Figure 3 see Figure 3 see Figure 3 see Figure 3 )))))
A. Clearances from the side of the firebox opening to any combustible wall should not
be less than 12 inches.
B. Clearances from the top of the firebox opening to the ceiling should not be less than
42 inches.
Mantel Clearances for Conventional Installation Mantel Clearances for Conventional Installation Mantel Clearances for Conventional Installation Mantel Clearances for Conventional Installation Mantel Clearances for Conventional Installation
INSTALLATION
Figure 2 - Figure 2 - Figure 2 - Figure 2 - Figure 2 - V V V V Ventilation Air fr entilation Air fr entilation Air fr entilation Air fr entilation Air from Outdoor om Outdoor om Outdoor om Outdoor om Outdoors s s s s
OUTLET AIR
OUTLET
AIR
INTAKE
AIR
INTAKE AIR
VENTILATED ATTIC
VENTILATED
CRAWL SPACE
TO
CRAWL
SPACE
TO
ATTIC
10
