USSC 27
PARTS LIST - 6041TP
1 69529 Pedestal 1
2 25410 Pedestal Bottom 1
3 25451 Pedestal Back 1
4 69478 Ash Pan 1
5 891137 Handle 1
6 25533 Damper/Cleanout Guide 2
7 25532 Cleanout Guide 2
8 25531 Ash Cleanout (Lower) 2
9 69528 Damper 1
10 891660 Burnpot 1
11 891059 Agitator 1
12 83529 Hair Pin 2
13 25524 Ash Cleanout (Inner) 2
14 69593 Igniter Tube Weldment 1
15 88118 Igniter Flange Gasket 1
16 80543 Igniter Cartridge 1
17 69516 Feed Door Assembly 1
18 891135 Spring Handle (Large) 1
19 25080 Door Latch 1
20 891705 Vermaculite Board (Herringbone) 1
21 69497 Louver Assembly 1
22 88116 Insulation (Kaowool) 1
23 86627
Exhaust Duct
1
24 88114
Exhaust Duct Weldment
1
25 80473 Exhaust Blower 1
26 88100
Exhaust Blower Gasket
1
27 80472 Distribution Blower 1
28 88106 Distribution Blower Gasket 1
29 69598 Hopper Assembly - Complete 1
30 80491 Micro Switch 1
31 891164 Auger Housing Weldment 1
32 891141 Auger 1
33 891132 Bottom Bushing
(
Retaining Ring - Pt #: 83534 )
1
34 69514 Top Bushing Plate Assy. 1
35 891248 Bottom Plate Retainer 1
36 891195 Drive Motor Bracket 1
37 891169 Hose (2 per) 0.167 ft
38 891180 Auger Cover
39 88120
Gasket, 0.188 x 1.0 Flat FbrGlss.
0.25 ft
40 80488 Drive Motor (Auger) 1
41 80456 Drive Motor (Agitator) 1
42 891083 Sprocket, Motor 1
43 891057 Sprocket, Shaft 1
44 89105 8 Chain - 36 Links 1
45 69594 Primary Bushing Assembly 1
46 88111 Agitator Bracket Gasket 1
47 69595 Secondary Bushing Assembly 1
48 891706 Drive Shaft - Agitator 1
49 80549 Pressure Switch 1
50 25648 Pressure Switch Bracket 1
51 891121 Silicone Hose 0.4 ft
52 83564 Hose Clamp 1
53 89586 Auger Nipple 1
54 80381 110°F Snap Disc (Low Limit) 1
55 80390 170°F Snap Disc (High Limit) 1
56 69506 Cabinet Support, Top/Left 1
57 25448 Support Frame, Back/Left 1
58 69505 Cabinet Support, Top/Right 1
59 25447 Support Frame, Back/Right 1
60 25412 Right Cabinet Side 1
61 25411 Left Cabinet Side 1
62 80575 PCB, Circuit Board 1
N/S 80485 Wiring Harness, Main 1
63 25682 Cabinet Back 1
64 80462 Receptacle, 3-Prong 1
65 80461 Power Supply Cord 1
66
891707 Top/Lid Assembly 1
67
68 891148 Plastic Handle 1
69 25493 Corner Trim 2
70 25468 Trim, Front Panel 1
71 25472 Trim, Left Panel 1
72 25471 Trim, Right 1
N/S = Not Shown
Key Part No. Description Qty. Key Part No. Description Qty. Key Part No. Description Qty. Key Part No. Description Qty.
