USSC Page 9
KEY PART # DESCRIPTION QTY.
1 69315 FIREBOX WELDMENT 1
2 C97999 WATER COIL COVER GASKET 1
3 24220 INSIDE COVER PLATE 1
N/S C23799 12 x 3/4" TEKS SCREW 3
N/S 83236 1/4-20 x 3/4" HX SCREW 4
4 25085 FEED DOOR 1
N/S 88033 3/8" ROPE GASKET (FEED DOOR) 4.25 FT.
N/S C21390 7/32 x 1 ROLL PIN (FEED DOOR) 2
5 24482 PRESSURE FLAP 1
N/S 88075 3/4 FLAT ROPE GASKET 1 FT.
N/S C21390 7/32 x 1 ROLL PIN (PRESSURE FLAP) 2
6 69326B FEED DOOR HANDLE ASSY. 1
7 83379 1/4-20 x 1 BOLT 1
8 83261 1/4-20 LOCK NUT 1
9 24485 ASH DOOR 1
N/S 88033 3/8 ROPE GASKET 2.29 FT.
1 0 25047B ASH DOOR HANDLE 1
N/S C21390 7/32 x 1 ROLL PIN (ASH DOOR) 2
1 1 83379 1/4-20 x 1 BOLT 1
1 2 83261 1/4-20 LOCK NUT 1
1 3 24382 SPIN DAMPER 1
1 4 83471 5/16-18 x 1-3/4" CARR. BOLT 1
1 5 83423 5/16-18 HEX LOCK NUT 1
1 6 69068 ASH DRAWER ASSY. 1
1 7 24501 SMOKE CURTAIN 1
1 8 83445 1/4-20 x 1-1/4" BOLT 2
1 9 83261 1/4-20 LOCK NUT 2
2 0 23787 SMOKE DOOR CLIP 2
2 1 89799 STUB COLLAR 1
2 2 24528 DAMPER ROD 1
N/S 83874 1/8 DIA. x 1-1/2" COTTER PIN 1
2 3 69321G CONTROL CENTER 1
* * 69323 CONTROL CENTER (STAINLESS STEEL) 1
2 4 69097 FORCED DRAFT BLOWER ASSY. 1
2 5 80129 THERMOSTAT 1
2 6 89574 SPRING HANDLE (DAMPER ROD, SHAKER) 2
2 7 89849 HOOK SPRING HANDLE (FEED, ASH DOOR) 2
2 8 69082 JUNCTION BOX ASSY. 1
2 9 69069 SHAKER GRATE HANDLE 1
3 0 40369 SHAKER GRATE FRAME 2
3 1 40349 SHAKER GRATE 2
3 2 40366 FIREBOX LINER 2
3 3 24496 FRONT HEAT PLATE 1
3 4 24487 FURNACE HEAT PLATE 1
3 5 89066 FIREBRICK 1 0
3 6 25014G CABINET TOP 1
* * 25015 CABINET TOP (STAINLESS STEEL) 1
3 7 25016G CABINET RIGHT SIDE 1
* * 25017 CABINET RIGHT SIDE (STAINLESS STEEL) 1
3 8 25018G CABINET LEFT SIDE 1
* * 25019 CABINET LEFT SIDE (STAINLESS STEEL) 1
3 9 25025B SIDE FILLER 2
4 0 25020G BOTTOM FRONT 1
* * 25021 BOTTOM FRONT (STAINLESS STEEL) 1
4 1 891049 CATCH 2
N/S 891048 BALL STRIKE 2
4 2 25022G CABINET DOOR 1
* * 25023 CABINET DOOR (STAINLESS STEEL) 1
N/S 69318B TOP CABINET DOOR HINGE 1
N/S 69319B TOP CABINET DOOR HINGE 1
N/S 851405 ASHLEY SCRIPT LOGO 1
4 3 25024B LINER, CABINET DOOR 1
4 4 89943 DOOR KNOB 1
4 5 C60456 1050 CFM DISTRIBUTION BLOWER 1
Parts
N/S = NOT SHOWN ** = USED ON 24AZ
FOR MODEL(S): 24AG, 24AZ
