USSC Page 7
Parts
KEY PART # DESCRIPTION QTY.
1 69072 FIREBOX WELDMENT 1
2 C97999 WATER COIL COVER GASKET 1
3 24220 INSIDE COVER PLATE 1
N/S C23799 12 x 3/4" TEKS SCREW 3
N/S 83236 1/4-20 x 3/4" HX SCREW 4
4 25085 FEED DOOR 1
N/S 88033 3/8" ROPE GASKET (FEED DOOR) 4.25 FT.
N/S C21390 7/32 x 1 ROLL PIN (FEED DOOR) 2
5 24482 PRESSURE FLAP 1
N/S 88075 3/4 FLAT ROPE GASKET 1 FT.
N/S C21390 7/32 x 1 ROLL PIN (PRESSURE FLAP) 2
6 69077 FEED DOOR HANDLE ASSY. 1
7 83379 1/4-20 x 1 BOLT 1
8 83261 1/4-20 LOCK NUT 1
9 24485 ASH DOOR 1
N/S 88033 3/8 ROPE GASKET 2.29 FT.
10 24486 ASH DOOR HANDLE 1
N/S C21390 7/32 x 1 ROLL PIN (ASH DOOR) 2
11 83379 1/4-20 x 1 BOLT 1
12 83261 1/4-20 LOCK NUT 1
13 24382 SPIN DAMPER 1
14 83471 5/16-18 x 1-3/4" CARR. BOLT 1
15 83423 5/16-18 HEX LOCK NUT 1
16 69068 ASH DRAWER ASSY. 1
17 24501 SMOKE CURTAIN 1
18 83445 1/4-20 x 1-1/4" BOLT 2
19 83261 1/4-20 LOCK NUT 2
20 23787 SMOKE DOOR CLIP 2
21 89799 STUB COLLAR 1
22 24528 DAMPER ROD 1
N/S 83874 1/8 DIA. x 1-1/2" COTTER PIN 1
23 69080 CONTROL CENTER 1
24 69097 FORCED DRAFT BLOWER ASSY. 1
25 80129 THERMOSTAT 1
26 89574 SPRING HANDLE (DAMPER ROD, SHAKER) 2
27 89849 HOOK SPRING HANDLE (FEED, ASH DOOR) 2
28 69082 JUNCTION BOX ASSY. 1
29 69069 SHAKER GRATE HANDLE 1
30 40369 SHAKER GRATE FRAME 2
31 40349 SHAKER GRATE 2
32 40366 FIREBOX LINER 2
33 24496 FRONT HEAT PLATE 1
34 24487 FURNACE HEAT PLATE 1
35 89066 FIREBRICK 10
36 24488 CABINET TOP 1
37 24489 CABINET RIGHT SIDE 1
38 24490 CABINET LEFT SIDE 1
39 C60456 1050 CFM DISTRIBUTION BLOWER 1 N/S = NOT SHOWN
FOR MODEL(S): 24AF
