Fuel Shutoff Valve
This valve should be shut when removing the engine or
placing the unit in long term storage.
On the SP 2020/3020, the shutoff valve can be ac-
cessed from the rear of the machine (Fig. 2).
On the SP 5020, the shutoff valve can be accessed by
removing the left side panel (Fig. 3).
2
1
Figure 2
1. Fuel shutoff valve 2. Hydraulic oil filter
1
2
Figure 3
1. Fuel shutoff valve 2. Hydraulic oil tank
Sand Pro 2020/3020/5020 Page 3 – 5 Engine
Engine
