Specifications
Item Description
Make / Designation Briggs and Stratton Vanguard, 4–Cycle, V–Twin Cylinder, OHV,
Air Cooled, Gasoline Engine
Horse Power
SP 2020/3020 16 HP @ 3600 RPM
SP 5020 18 HP @ 3600 RPM
Bore mm (in.)
SP 2020/3020 68.0 (2.677)
SP 5020 71.98 (2.834)
Total Displacement cc (cu. in.)
SP 2020/3020 480 (29.3)
SP 5020 570 (34.8)
Fuel Unleaded Regular Grade Gasoline
Fuel Capacity liters (gallons)
SP 2020/3020 16.1 (4.25)
SP 5020 20.8 (5.50)
Fuel Pump Pulsating Crankcase Vacuum
Governor Mechanical
Low Idle (no load) 1750 + 50 RPM
High Idle (no load) 3150 + 50 RPM
Intake and Exhaust Valve Seat Angle 45 _
Intake and Exhaust Valve Clearance (Cold) mm (in.) 0.10 to 0.15 (0.004 to 0.006)
Carburetor Single Barrel, Float Feed with Suppress Afterfire Solenoid
Engine Oil SAE 30 SE, SF, or SG
Oil Pump Internal Gear Driven Gerotor Type
Crankcase Oil Capacity liters (U.S. qt.) 1.66 (1.75) with filter
Starter 12 VDC
Alternator/Regulator 12 VDC 16 AMP
Spark Plug Champion RC12YC or NGK BKR4E or Equivalent
Spark Plug Gap mm (in.) 0.76 (0.030)
Engine
Sand Pro 2020/3020/5020 Page 3 – 3 Engine
