HD74HCT1G04
Rev.5.00, Jan.28.2004, page 6 of 7
Test Circuit
Pulse
generator
50
Ω
C
L
Input
Output
V
CC
Note: 1. C includes probe and jig capacitance.
L
Input
Output
90%
1.3 V
10%
t
THL
t
TLH
90%
1.3 V
10%
t
PHL
t
PLH
3 V
GND
V
OH
V
OL
90%
1.3 V
10%
90%
1.3 V
10%
r
t = 6 ns
f
t = 6 ns
•
Waveforms
