HD74HCT1G04
Rev.5.00, Jan.28.2004, page 4 of 7
Electrical Characteristics
T
a
= 25°C T
a
= –40 to 85°C
Item Symbol
V
CC
(V) Min Typ Max Min Max Unit Test Conditions
V
IH
4.5 to
5.5 2.0 — — 2.0 — Input voltage
V
IL
4.5 to
5.5 — — 0.8 — 0.8
V
4.5 4.4 4.5 — 4.4 — I
OH
= –20
µ
A V
OH
4.5 4.18 4.31 — 4.13 —
V
IN
= V
IL
I
OH
= –2 mA
4.5 — 0.0 0.1 — 0.1 I
OL
= 20
µ
A
Output voltage
V
OL
4.5 — 0.17 0.26 — 0.33
V
V
IN
= V
IH
I
OL
= 2 mA
Input current I
IN
5.5 — — ±0.1 — ±1.0
µ
A V
IN
= V
CC
or GND
Operating
current I
CC
5.5 — — 1.0 — 10.0
µ
A V
IN
= V
CC
or GND
Quiescent
supply current I
CCT
5.5 — — 2.0 — 2.9 mA One input V
IN
= 2.4 V,
other input V
CC
or GND
