Radio Shack TRC-512 - Manual (Page 13)

13
RECEIVER
Sensitivity (20 dB quieting) .......................... 0.5
µ
V
Squelch Sensitivity Threshold ...................... 0.5
µ
V
Modulation Acceptance Bandwidth ............. ±7 kHz
Spurious and Image Rejection ............... 20 dB min
Frequency Stability (0°C to 40°C) ............... ±1 kHz
TRANSMITTER
RF Energy Output .............................. 10,000
µ
V/m
@3 meters (FCC max)
Spurious and Harmonic Emissions ....... 20 dB min.
FM Hum and Noise ............................... 40 dB min.
Audio Distortion ..................................... 10% max.
Frequency Stability (0°C to 40°C) ............... ±1 kHz
Specifications are typical; individual units might
vary. Specifications are subject to change and im-
provement without notice.
