I/O Ports
15-45
15.10 Port 8
15.10.1 Block Diagram
Figs. 15-10-1 shows the block diagrams for port 8.
Fig. 15-10-1 Port 8 Block Diagram (P83 to P80)
Internal data bus
P8n
(n=3,2,1,0)
P...
Represents one bit of each register.
AN3(n=3)
to AN0(n=0)
P8nA
P8AD
P8nI
P8IN
IRQ7(n=3)
to IRQ4(n=0)
