For information on the spacers:
Please observe the chapter ”SPACERS” on
page 286.
Removing the spacers
1. Unscrew both countersunk screws (M6x16) on
the wheel hub.
2. Remove the spacer.
3. Fasten the brake disc with the short
M6x12 countersunk screws, part No.:
900.269.047.09. Tightening torque
10 Nm (7.5 ftlb.).
4. For wheel mounting without a spacer,
5 mm shorter wheel bolts (part No.:
996.361.203.02) must be used. Tighten-
ing torque: 130 Nm (96 ftlb.).
Please observe the chapter ”CHANGING A
WHEEL” on page 287.
Mounting the spacers
1. Remove wheel.
2. Unscrew both countersunk screws (M6x12) on
the break disc.
3. Fasten the spacer with the long M6x16
countersunk screws. Tightening torque
10 Nm (7.5 ftlb.).
4. Fit wheel. To do this use the longer wheel
bolts for fastening the wheels. Tightening
torque: 130 Nm (96 ftlb.).
Please observe the chapter ”CHANGING A
WHEEL” on page 287.
Long wheel bolt
- X: Bolt length approx. 50 mm
- Arrows: marks
Wheel bolt identifying features
The long wheel bolts are identified on the face
surface of the bolt head with GT or in red, or the
moveable spherical cap ring is galvanised in red.
The long wheel bolts must only be used together
with 5 mm spacers fitted.
The short wheel bolts are not marked in colour.
The short wheel bolts must only be used without
5 mm spacers fitted.
Practical Tips, Emergency Service
289
