E-9
Names of the Main Unit Parts
STA
NDB
Y
STA
TUS
MEN
U
AUDIO
MOUSE
S-VIDEO
VIDEO
RGB
SO
U RC E
AU
TO
DCM
STANDBY STATUS
MENU
S
O
U
R
C
E A
U
T
O
DCM
AUDIO MOUSE S-VIDEO VIDEO RGB
Ventilation slots
AC IN connector [E-19]
Remote control sensor [E-11]
RGB connector [E-14, 17]
S-VIDEO connector [E-16]
VIDEO connector [E-16]
AUDIO connector [E-18]
Ventilation slot
STATUS indicator [E-19, 54]
Buttons used in menu and
quick menu operations
[E-32, 33]
SOURCE button [E-24]
MENU button [E-33]
STANDBY indicator [E-19, 54]
AUTO button [E-24]
ENTER button [E-20]
STANDBY button [E-19]
SELECT ( ̆̄̇̈) buttons
DCM button [E-26]
MOUSE connector
A separately sold “VR-100 Remote Mouse Set”
(ordering code: 28-052) is required to use the
MOUSE connector.
Keystone Manual Adjustment
button [E-27]
